A300 GNSS Receiver

A300 GNSS Receiver

With the SinoGNSS K8 platform, the A300 GNSS receiver can achieve millimeter-level positioning accuracy. The A300 is a universal GNSS receiver compatible with multiple sensors for various monitoring tasks, which is one of the best choices for monitoring solutions. SinoGNSS A300 integrated GNSS module, GNSS antenna, and communication module in one compact receiver. It is especially designed for monitoring solutions.

social media:

Features

01.Millimeter-level Accuracy

02.Compatible with multiple external sensors

03.Easy Configuration via Navigate Master

04.Support remote monitoring & management

05.Large 8G memory for loop recording

06.IP68, anti-vibration and anti-lightning for harsh environments

07.Support 4G/Bluetooth/UHF for flexible communication

08.24/7 Operation – MTBF > 50,000 hours

1

Full-constellation tracking

With 965 channels, the A300 can track all existed and planning satellite constellations, which include GPS, GLONASS, Beidou, Galileo, IRNSS, SBAS and QZSS.

1

Rugged Design

Featured IP68 waterproof and dustproof, the anti-vibration and anti-lightning GNSS receiver is workable in harsh environments.

1

Monitoring

The A300 is widely used for monitoring geological disasters, mines, hydraulic and hydroelectric engineering, bridges, high rise buildings.

Specifications

Performance

Channels

965

Satellites tracking

GPS: L1C/A, L1C, L2P, L2C, L5
BDS: B1I, B2I, B3I, B1C, B2a, B2b
GLONASS: G1, G2, G3
Galileo: E1, E5a, E5b, E6c, E5 AltBOC
QZSS: L1C/A, L2C, L5,L1C
IRNSS: L5

SBAS: L1C/A

Time accuracy 20 ns

Post Processing

Horizontal: 2.5 mm + 1 ppm
Vertical: 5 mm + 1 ppm

Single Baseline RTK

Horizontal: 8 mm+1 ppm
Vertical: 15 mm+ 1 ppm

DGPS

<0.4 m RMS

SBAS 1 m 3D RMS
Standalone 1.5 m 3D RMS

Physical

Dimension

φ205mm*126.5mm

Weight

≤2kg

Working Temperature

-40℃~+70℃

Storage Temperature

-55℃~+85℃

Input voltage

+3.3 V ± 5% DC

Humidity

100% No-condensing

Waterproof and Dustproof

IP68

MTBF

≥50000h

Input Voltage

6-36 VDC, overvoltage protection

Power Consumption

<2w

Communications

1 14-pin Lemo port

2Serial port(RS232, RS485), USB port(USB2.0), power, switching value support external sensors input

2 SIM card slots

4G modem, dual SIM dual standby

1 TNC connector

UHF modem

UHF modem Frequency range: 410MHz-470MHz Transmit power: 0.5-2 W adjustable Range: 8-15 km

Bluetooth

4.1/2.1+EDR, 2.4GHz

Network

TCP/IP、MQTT、Ntrip

Indicator LEDs

4 LEDs, indicating power, satellite searching, correction data and GSM status

Documents

SinoGNSS A300 GNSS Receiver.pdf

Release Date:2023-02-17

Version:Version:2.0
