G200 GNSS Receiver
social media:
Features
01.Full constellations and multi-frequency
02.High-accuracy Positioning
03.Ideal for RTK Solution
04.Compact, Rugged Design
05.Multiple Data Collection Device Choices via Bluetooth Connection

Full constellations tracking
SinoGNSS G200 is a rugged, compact, wearable GNSS receiver tracking full constellations and multi-frequency.

Ideal for CORS
The G200 is a cost-effective GNSS receiver that provides centimeter accuracy positioning by connecting any running CORS system.

Intuitive workflow
The G200 is able to provide easier survey workflow via Survey Master Wizard function, improving productivity for both beginners and professional surveyors.
Video


Specifications
Performance |
Signal tracking Channels: |
965 channels |
Satellite tracking: |
GPS L1/L2/L5, BeiDou B1/B2/B3/B1C/B2a/B2b, GLONASS L1/L2, Galileo E1/E5a/E5b/E6/ E5AltBOC, QZSS L1/L2C/L5, IRNSS L5 and SBAS |
|
RTK Horizontal accuracy: |
8 mm + 1 ppm |
|
RTK Vertical accuracy: |
15 mm + 1 ppm |
|
Post Processing Horizontal accuracy: |
2.5 mm + 1 ppm |
|
Post Processing Vertical accuracy: |
5 mm + 1 ppm |
|
Initialization time: |
less than 10 s |
|
Physical |
Size(W 脳 H): |
13.7cm 7.2cm 5.04cm |
Weight (incl. supplied two batteries): |
<0.35kg |
|
Operating temperature: |
-20 C to + 60 C |
|
Shock: |
Designed to survive a 1.5 m drop onto concrete |
|
Humidity: |
100% non-condensing |
|
Waterproof and dustproof: |
IP65 |
|
Power consumption (3 constellations): |
1.6 W |
|
Communications |
Serial port: |
1 9pin Fischer |
Protocol: |
Ntrip (software based) |
|
Correction data I/O: |
RTCM 2.X, 3.X, CMR (GPS only), CMR+ (GPS only) |
|
Position data output rates: |
1 Hz, 2 Hz, 5 Hz, 10 Hz, 20 Hz |
|
Bluetooth® : |
V4.0, compatible with Android™ and WindowsTM mobile OS |
