K801 GNSS Module

K801 GNSS Module

The K801 GNSS module is a high-performance, low-cost GNSS positioning module. Featuring surface mounted design, smaller size of 12mmx 16mm and low power consumption, K801 is ideal for consuming market and solutions such as Internet of Things, intelligent driving, UAV and robotics.

social media:

Features

01.Support BDS-3, BDS-2, GPS, GLONASS, Galileo, QZSS

02.Support L1/L5 bands

03.Small size, 12mm×16mm

04.Surface-mounted design to integrate

05.On board IMU

06.0.15W low power consumption

1

Dual-band & multi-constellation

K801 adopts high-precision Soc chip and supports BDS-3, GPS,  BDS-2, GLONASS, Galileo, QZSS and L1/L5 dual-frequency  signals, which can significantly reduce signal acquisition when  interrupted and  improve positioning accuracy

1

INS+GNSS navigation

K801 is designed with an onboard high-precision IMU module, which  can provide continuous and high-quality positioning data with inertial  navigation fusion algorithm.

1

Easy to Integrate

Featuring surface mounted design, smaller size of 12mm × 16mm  and low power consumption, K801 is compatible with mainstream  GNSS modules, allowing users to integrate more easily.

Specifications

Performance

Channels

372

Satellites tracking

GPS: L1 C/A, L5
BeiDou: B1I, B2a
GLONASS: G1
Galileo: E1, E5a
QZSS
SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM

Post Processing

Horizontal: 2.5 mm + 1 ppm
Vertical: 5 mm + 1 ppm

Single Baseline RTK

Horizontal: 8 mm+1 ppm
Vertical: 15 mm+ 1 ppm

Initialization time

<5 s

Physical

Size (L x W x H)

12 mm × 16 mm × 2.4 mm

Weight

1.6 g

Hardware interface

LGA 24 pin

Power consumption

0.15W(Anti-interference on)

Input voltage

+3.3 V ± 5% DC

Operating temperature

-40 °C to + 85 °C

Storage temperature

-55 °C to + 95 °C

LNA Power

External: +3.3V ~ +5V ± 5%VDC @ 0-100mA

LNA Gain

0 ~ 32dB (suggested)

Impedance Matching

50 Ω

Battery life Battery life

Communications

LVTTL ports

2

SPI

1

Event Markers input

*

Pulse Per Second (PPS) output

*

Indicator pins show tde working status

1

Correction data I/O

RTCM 2.X, 3.X, CMR*, CMR+*

Position data output

NMEA-0183, ComNav Binary*

* Indicates supportable through future firmware upgrades
